Outdoor LED Video Display

Outdoor LED Video Display
Send Inquiry
Product Code : 1260
Brand Name : qiangli
Price And Quantity
  • Minimum Order Quantity
  • 01 Square Foot
  • Price
  • 5500 INR/Square Foot
  • Price Range
  • 3000.00 - 4500.00 INR/Square Foot
Product Specifications
  • Water Proof
  • water proof
  • Power Supply
  • 240
  • Body Material
  • mild steel
  • Product Type
  • video display system
  • Display Function
  • video
  • Application
  • Advertisements
  • Working Voltage
  • 240
  • Screen Dimension
  • customized size
  • IP Rating
  • ip67
  • Working Temperature
  • -10 To +60 Celsius (oC)
  • Size
  • 192mm*192mm
  • Color
  • Full color
  • Warranty
  • 3 years
Product Description

Pixel led is leading manufacturers and optimum supplier of different types of led screen.

  • The Best Quality of LED Screen in full HD resolution.
  • With High quality HD performance and HD graphics.
  • Standard calibrated Power Supply.
  • And Very competitive price factor in this.

Technical Specification

Module Parameter: hd outdoor led display screen p4.81 outdoor led screen 2 by 3 meters led screen

Pixel pitch

4.81mm

Pixel Density

43,222dots/m²

Pixel configuration

1R1G1B

LED type

3-in-1 black SMD2727

Module size

W250 x H250mm

Module weight

600g

Module resolution

W52 x H52dots

Module quantity

16 pcs/m

Min. Viewing Distance

4.81m

Brightness

6500cd/m²

Viewing Angle

120°

Driving Mode

1/13scan constant current driving

Interface

HUB75

Input voltage

4.8-5.5VDC

Max. Power Consumption

680w/m²

Avg. Power Consumption

272 w/m²

Max. Current

8.5A

Frame rate

60 frames/s

Refresh Rate

1920Hz

Defective Dots Rate

<0.0001 (LED display line standard:  0.0003)

Decay Rate

5%/year

Brightness Conformity

>95%

MTBF

10000 hours

Lifespan

50000 hours

Protective function

Over-heat/Over-load /Power-down /Power-leakage/Lightning

-protection etc.

Operating Temperature

-10 ~+40

Operating Humidity

10-85% no condensation

Storage Temperature

-30~+60

Storage Humidity

10-85% no condensation

control system parameter

Color temperature

Adjustable by software.

brightness level

256 levels,automatic or manual adjustment

control way

computer,real-time,offline,wireless,internet etc.

communication distance

cat5 UTP 100 meters,max.130 meters;or optical fiber

packing P4.81 led screen for rent /led for display case /led for display cabinet

carton

20pcs/carton,size:565x290x290mm,weight:12.8kg

Trade Information
  • FOB Port
  • North West Delhi
  • Payment Terms
  • Cash Against Delivery (CAD)
  • Supply Ability
  • 1000 Square Foot Per Week
  • Delivery Time
  • 1 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Free samples are available
  • Packaging Details
  • packed in hard wooden box
  • Main Domestic Market
  • All India
  • Certifications
  • iso certified
